Copies 1 - Title: Service Manual SHARP AR SME, Author: dientumayvanphong. com, Length: 94 pages, Published: Download it here-->singmoundupanvie.ml%20ar%20service% 20manualhtml thanks for rating good luck. DOWNLOAD SERVICE MANUAL SHARP AR HDGRSMHIZZ | PDF | 53 Pages | KB | DOWNLOAD SERVICE MANUAL SHARP AR.

SlideShare Explore Search You. Submit Search. Successfully reported this slideshow. We use your LinkedIn profile and activity data to personalize ads and to show you more relevant ads.

You can change your ad preferences anytime. Upcoming SlideShare. Like this document? Why not share! An annual anal Embed Size px.

Start on. Show related SlideShares at end. Start on. Show related SlideShares at end. WordPress Shortcode. ElmerFelix1 Follow. Published in: Full Name Comment goes here. Are you sure you want to Yes No. Be the first to like this.

No Downloads. Views Total views. Actions Shares. Embeds 0 No embeds. No notes for slide. Sharp ar service manualpdf 1. Caution : If the machine is moved from a cool place to a warm place, condensation may form inside the machine.

Operation in this condition will cause poor copy quality and malfunctions. Leave the machine at room temperature for at least 2 hours before use.

The machine should be installed near an accessible power outlet for easy connection and disconnection. Be sure to connect the power cord only to a power outlet that meets the specified voltage and current requirements. Also make certain the outlet is properly grounded.

You might also like: SONY PSP 3004 MANUAL PDF

Note : Connect the machine to a power outlet which is not used for other electric appliances. If a lighting fixture is connected to the same outlet, the light may flicker. Be sure to allow the required space around the machine for servicing and proper ventilation. Copy mode A. Type B. Machine composition 1 Option C. Document E. Paper type setting No No No Heavy paper setting is enabled. Paper size changing method The paper guide is set by the user.

Multi copy G. Warm-up time H. Copy magnification ratio I. Print density J. Void width K. Auto duplex L. Auto shut-off O The conditions are set by the user program.

Other specifications O. Package form P. External view Q.

Power source R. Digital performance T. Supply system table A. Environmental conditions A. Transport conditions 1 Transport conditions 2 Storage conditions B. Use conditions C. Life packed conditions Photoconductor drum 36 months from the production month Developer, toner 24 months from the production month 3. A for this model. Appearance 2. This example is of the inch series display. Motor, solenoid, clutch No. Sensor, switch No.

PWB unit No. Cross sectional view No. Adjustment item list 2. Copier adjustment A. Process section 1 Developing doctor gap adjustment 1 Loosen the developing doctor fixing screw A.

1 Suggested Answer

Perform the same procedure for the front and the rear frames. If it is within the specified range, then fix the doctor fixing screw with screw lock. Do not use paper clip, which is too heavy to make a correct adjustment.

Put the developing unit horizontally for this adjustment. Mark the point on the MG roller which is on the extension line from the needle tip. If the distance is not within the specified range, loosen the fixing screw A of the main pole adjustment plate, and move the adjustment plate in the arrow direction to adjust.

Sharp AR-5516 / AR-5520. Service Manual

A Process section 1 Developing doctor gap adjustment Developing doctor gap adjustment 2 MG roller main pole position adjustment MG roller main pole position adjustment 3 Developing bias voltage check 4 Main charger voltage check B Mechanism section 1 Image position adjustment SIM 2 Main scanning direction FR direction distortion balance adjustment No.

The voltage is outputted in the grid bias High output mode during warming up, and in the grid bias Low output mode when warming up is completed. Mechanism section Note: If a jam error or paper empty occurs during copying in the adjustment by the simulation, the image data is not saved, and therefore recopying is required.

OC image lead edge position adjustment SIM Note:In advance to this adjustment, the sub scanning magnification ratio adjustment must be performed. If necessary, perform the following adjustment procedures. The print start position is shifted inside the document edge. A line may be printed by scanning the document edge. Note:Before performing the 2nd print surface lead edge position adjustment and the lead edge void adjustment, be sure to perform the 1st print surface lead edge position adjustment in advance, and be sure to perform the 2nd print surface lead edge position adjustment and then the lead edge void adjustment in this sequence.

Note:Since the printed copy is used as a test chart, put the scale in paralled with the edge lines. The currently set adjustment value is displayed. The correction value is stored and a copy is made.

Note:Before performing the 2nd print surface rear edge void adjustment, be sure to perform the 2nd print surface lead edge position adjustment. Never reverse the sequence.

Compare the copy and the test chart.

AR-5520 AR-5516 AR-5520S AR-5516S AR-5520D AR-5516D

If necessary, perform the following adjustment procedure. After completion of warm-up, shading is performed and the currently set off center adjustment value of each paper feed port is displayed. Side edge void area adjustment SIM Note:Before performing this adjustment, be sure to check that the paper off center adjustment SIM is completed.

Compare the 2nd copy and the test chart. Be sure to check the 2nd copy. The correction value is stored.

Reduce 1: 0. At that time, if the front frame side and the rear frame side of No.

If one of them is in contact with the positioning plate, perform the adjustment of 4. Before performing this adjustment, be sure to perform the horizontal image distortion adjustment in the laser scanner section.

Sharp ar 5516 service manual - Computers & Internet

A3 11" x 17" white paperGlass holding plate Allow a little space. Do not move the mirror base drive pulley shaft. These lines must be correctly parallel to each other. Fit the paper edge with the glass holding plate edge. Note:Do not adjust the rail on the rear side. If the rail on the rear side is adjusted, an error may occur. Only the rail on the front side can be adjusted.

Be careful to avoid this. The set value is stored and a copy is made.When the set value is increased, the gamma is increased to increase the contrast. Center Copy paper A3 or 17" x 11" 2 Make a normal copy from the bypass tray.

If paper is not fixed, the operations cannot be guaranteed. If this number is exceeded. When the destination is of inch series. The default value depends on the destination.

Page 51 When the destination is of AB series, print data are made in A3 size. Connect the machine to a power outlet which is not used for other electric appliances. SlideShare Explore Search You.
